HTLNUZD Radiolink AT9S Pro 2.4G Radio Controller Transmitter 10/12 Channels DSSS & FHSS Communication with R9DS Receiver, for RC FPV Racing Drone Truck Car Boat (Grey-Radiolink AT9S Pro)

Specifications:Name:AT9SProTransmitterChannels:10CH/12CHSignal:SBUS/PWM/PPM/CRSFFrequency:2.4GHzISMBands(2400MHzto2483.5MHz)ChannelBandswidth:5.0MHzSpreadSpectrum:DSSS&FHSS/CRSFModulationMode:QPSKAdjacentChannelRejection:>38dbm TransmissionPower:DSSS&FHSS<100mW(20dbm)CRSF:10mW/25mW/100mW/500mW/1W/2W(Optional)OperatingCurrent: DSSS&FHSS <90mA@12VCRSF Depends on the Transmission Power SelecteOperating Voltage: 7.4~18.0V4096 Section PrecisionScreen: 2.8inches 16 Colorful Screen, 240*320 PixelsChannel:12 Channels , 5-12 Channels are CustomizedSize: AT9S Pro 183*100*193mmWeight: 0.88kgControl Range: 4 Kilometers in the Air (Maximum Range is Tested in an Unobstructed Area Free of Interference)Compatible Receivers:12CH - R12DSM, R12DS,10CH-R9DS, R6DS,R6DSMCRSF Protocol: Receiver from BLACKSHEEPR9DS Receiver Specifications:Signal: SBUS,PWMChannel: PWM 9 Channels, SBUS 10 ChannelsControl Distance: 900m on Ground,1500m AirWorking Voltage: 4.8-10VWorking Current: 38-45mA（Input Voltage: 5V)Size:43*24*15mmWeight:11gPackageInformation:PackageSize:18.5*10.5*19.5cmPackageWeight:880gGeneralBoxPackagePackageIncluding:1*AT9SProTransmitter(Mode2)1*R9DSReceiver1*Radiolink Lanyard

• 【Excellent Anti-interference】DSSS&FHSS communication technology makes AT9S Pro transmitter with stable transmission signal and long range control up to 2.1 miles(3.4km) in air.
• 【Powerful features 】10/12 channels, 3ms Fast Response, Real-time telemetry(work with PRM-03), Throttle Cut, Dual-Rate, Programmable Mix Control, Fail Safe, Reverse Polarity Protection, Multiple Model Options, etc. a good choice for beginner and expert.
• 【Additional Function】3 in 1 multi-function port, support most of simulator, TBS Crossfire Protocol (915 Module), Trainer mode support.
• 【Safety Remind】RSSI alert, radio/receiver/model low voltage alarm. With DD sounds, vibration, and words alarming display on the LCD screen to remind when you are in noisy surroundings.
• 【Strong compatibility】Works with R12DS, R12DSM, R9DS, R6DS, R6DSM. 15 models data storage and quicks to switch models-helicopter, quad, airplane, glider, cars, boats.
